dump heights
• 36”, 48”, 60”

Backplate
diameter
• 24”

platform size
• 24” x 24”

casters/ wheels
• 8” dia. x 2” wide

retaining bar
• Fixed
• Adjustable

Safety
• Velocity fuse (in case
  of hose failure it will
  stop unit from coming
  down)
• Down flow control
  - built into power
  pack, (pressure
  compensated)
• Heavy duty floor lock

power options
A/C 110 volt /1/60
Hand held pendant
(standard)
A/C 230/460/575/3/60
power
Optional
Air/Hydraulic
Foot control (standard)
Hand held pendant
(optional)

Options
• Increase/decrease:
  platform, diameter of   backplate, dump
 height, tilt angle
• Chute attachments
• Fixed retaining bars
• Stainless Steel
• Galvanized
• “Steel-it” epoxy
  finish paint
• Limit switches
• “V” groove back plate
