Platform Sizes
• 24” wide x 36” long
to 72” wide x 72” long
base sizes
• Standard 24”,36”,48” wide x 36”,48” long
travel
• 48”, 72” vertical travel
lowered heights
• 12”, 18”
safety
• Velocity fuse is standard on each cylinder
• Heavy duty hydraulic cylinders - chrome plated
  rod with polyurethane seals

Power supplies
A/C 110/1/60 volt (standard)
Hand or foot operated
A/C 460/575/3/60 volt (opt.)
Hand or foot operated
Air/Hydraulic
Foot operated (standard)
Hand operated (optional)
• Internally mounted
• Easily accessible for
  maintenance or repair
• Motors - Single phase 1 h.p.
  and three phase 1-1/2 h.p. -
 hand or foot operated
 standard

Maintenance
• Hinged table top provides
  easy access to power unit
 and cylinders
• Self lubricated bronze
 bushings on all wear points

options
• Oversized platforms
• Beveled edges for pit
  mounting
• Eye-bolts for pit mounting
• Rotating tops
 - spring detents
 - manual detents
• Roller conveyor,
  Ball transfer tops
• Bellow safety skirting
• Safety tape switch
• Semi-portable
• Portable
