The portable tote box
tilter is designed to make the lifting, handling and
positioning of small parts containers easy on the worker’s back.
Tilts hydraulically to 94°
Makes parts easily reachable
- Prevents back strain
- Increases productivity.
Power supplies
D/C Battery
Joy Stick Controlled
Air/Hydraulic
Foot Pedal
(80 p.s.i., 20 c.f.m. min.)
hand held pendants optional
A/C 115/60/1
Hand Held Pendant
Options
• Forks - longer/shorter, higher/lower to 2”,
wider / narrower
• Adjustable Forks
- 6”-36”
• Slip on Platform
• Tray Attachments
• Larger Back Plates
